Chip Tuning Mercedes-Benz Sprinter
Up to 30% more power for your Mercedes-Benz Sprinter
The Mercedes-Benz Sprinter (2007 →) is listed with 4 generations and 20 engines. For 19 turbo engines, choose the GAN GT or GAN GTL tuning module: the GAN GT adds +24 to +54 hp (GAN GT from 329 EUR, GAN GTL from 219 EUR). For 1 naturally aspirated engine, choose the GAN GA or GAN GA+: the GAN GA+ adds +17 to +17 hp (GAN GA+ from 189 EUR).
Which Mercedes-Benz Sprinter do you have?
Start with the model year and chassis code. Within a generation, choose your engine by the power output in your vehicle documents.
Mercedes-Benz Sprinter tuning: what the GAN module does and doesn’t do
More power and torque without an ECU remap or replacing any parts. The tuning module only adjusts the engine sensor signals.
- Bluetoothsmartphone mode control
- 18 mappingsfine tuning for your engine

- 15 minutesfitted to the factory connectors
- IP67water and dust protection
- +54 hpwith the GAN GT on turbocharged engines
+24 to +54 hp across the Mercedes-Benz Sprinter range with the GAN GT or GAN GTL.
- +17 hpwith the GAN GA+ on naturally aspirated engines
Naturally aspirated Mercedes-Benz Sprinter engines: +17 to +17 hp.
- GAN APPpower control via smartphone
SPORT, DYNAMIC, ECO and STOCK modes in the GAN app.
- 50 daystest drive
Enhanced performance or your money back, excluding delivery costs.
Mercedes-Benz Sprinter chip tuning: engines and generations
Mercedes Sprinter tuning: the badge is a weight class
The first digit of the 313 CDI badge is the weight class, not the engine. Under that one badge the W906 hides two different diesels. The OM 646 ran until summer 2009 and the OM 651 after it, both with 129 hp and 305 Nm. A tuning box for the Sprinter follows the engine, not the badge.
With the GAN GT the 313 CDI reaches 167 hp and 391 Nm, against 129 hp and 305 Nm as standard. These are the stated gains for this engine type, not a dyno reading of your car. The 319 CDI has the V6 OM 642 with 190 hp and 440 Nm from 2009. The third generation, the W907 and W910, was presented in February 2018.
Mercedes-Benz Sprinter chip tuning: questions
How much power does the GAN GT add to the Sprinter 319 CDI?
With the GAN GT the 319 CDI reaches 244 hp and 551 Nm.
Mercedes Sprinter chip tuning: tuning box or ECU remap on a working van?
An ECU remap replaces the factory software in the engine control unit. A tuning box leaves the factory software as it is. Your manufacturer's warranty is preserved: the ECU software is never changed, and the module can be removed at any time.
Is a tuning module the same as a Stage 1 tune?
Not quite. Stage 1 usually means an ECU remap without replacing any parts. The tuning module also works without replacing parts, but it does not change the ECU software: it adjusts the sensor signals, comes off in about a minute, and the OFF button in the app restores the factory settings.
