Chip Tuning Suzuki Jimny
7 engines · +8 to +26 hp
Suzuki Jimny: 7 engines — 5 petrol and 2 diesel. Gains range from +8 to +26 hp, with up to +60 Nm of torque. GAN GTL from 219 EUR, GAN GT from 329 EUR. GAN GA+ from 189 EUR.
All Suzuki Jimny engines: exact gains
STOCK output, output with GAN, gain and price for each module. Diesel and petrol engines are listed separately.
| Engine | STOCK → with GAN | Gain | Tuning modules and prices | |
|---|---|---|---|---|
| Diesel · 2 engines | ||||
| 1.5 DDiS86 hp / 200 Nm | +26 hp+60 Nm |
GTL — 219 EUR · 108 hp GT — 329 EUR · 112 hp |
Select → | |
| 1.5 DDiS65 hp / 160 Nm | +20 hp+48 Nm |
GTL — 219 EUR · 82 hp GT — 329 EUR · 85 hp |
Select → | |
| Petrol · 5 engines | ||||
| 1.5i102 hp / 130 Nm | +12 hp+16 Nm |
GA — 189 EUR · 114 hp GA+ — 189 EUR · 114 hp |
Select → | |
| 1.3i80 hp / 110 Nm | +10 hp+13 Nm |
GA — 189 EUR · 90 hp GA+ — 189 EUR · 90 hp |
Select → | |
| 1.3i80 hp / 104 Nm | +10 hp+12 Nm |
GA — 189 EUR · 90 hp GA+ — 189 EUR · 90 hp |
Select → | |
| 1.3i85 hp / 110 Nm | +10 hp+13 Nm |
GA — 189 EUR · 95 hp GA+ — 189 EUR · 95 hp |
Select → | |
| 0.7i64 hp / 103 Nm | +8 hp+12 Nm |
GA — 189 EUR · 72 hp GA+ — 189 EUR · 72 hp |
Select → | |
Each engine has its own tuning module: GAN GT / GTL or GAN GA / GA+. Prices are per tuning module and include the current discount.
Not sure which engine you have?
The badge alone is not enough: in this generation, the same engine designation came in different power outputs, each with its own calibration. Check the power output in your registration document and find the matching row.
Same badge, different factory power outputs in this generation:
Suzuki Jimny tuning: what changes
The tuning module sits between the sensors and the engine control unit (ECU) and adjusts their signals. Your manufacturer’s warranty is preserved: the ECU software is never changed, and the module can be removed at any time.
- Bluetoothsmartphone mode control
- 18 mappingsfine tuning for your engine
- 15 minutesfitted to the factory connectors
- IP67water and dust protection
- +26 hpbest in this generation
1.5 DDiS 86 hp → 112 hp. The other engines gain from +8 hp; see the table for each one.
- +60 Nmfor diesels
Diesels gain mainly torque: +48 to +60 Nm.
- up to +12%with the GAN GA+ on naturally aspirated engines
For 5 naturally aspirated engines: GAN GA / GAN GA+ tuning modules; see the table for each engine’s figure.
- 50 daystest drive
Enhanced performance or your money back, excluding delivery costs.
What makes the Suzuki Jimny special
Jimny tuning: 1.5 can mean two different engines
On a Suzuki Jimny, tuning with a tuning box starts with the badge, because 1.5 can mean two engines with nothing in common. The 1.5 DDiS is a Renault K9K diesel with 65 hp from April 2004 and 86 hp from December 2005, built by Santana in Spain as the JB53. The 1.5 petrol is the naturally aspirated K15B of the Jimny IV, with 102 hp and 130 Nm. In Europe it was sold from October 2018 as a passenger car until 2020, and later as a two-seat van.
The 86 hp diesel has an intercooler, which the 65 hp version lacks. They need different modules: the DDiS works with the GAN GT, the K15B with the GAN GA+.
The 1.3 changed three times
The naturally aspirated 1.3 comes in three versions: the G13BB with 80 hp and 104 Nm from October 1998 to December 2000. Then the M13A with 80 hp and 110 Nm from January 2001 to May 2005, and from June 2005 the M13A VVT with 85 to 86 hp. The rear-wheel-drive version, with a five-speed manual only, was offered only from 1998 to 2000. In the catalogue the 1.3 with 80 hp and the 1.3 with 85 hp both use the GAN GA+.
Generations and names
The third generation covers the JB33, JB43 and JB53 bodies, and the fourth generation is the JB74. The Jimny IV has one engine, the K15B, with ALLGRIP PRO four-wheel drive, a five-speed manual or a four-speed automatic, and three doors. The Jimny Sierra is the Japanese name for the versions wider than the kei car, with 1.3 or 1.5 litres. In English the car is simply the Suzuki Jimny.
Suzuki Jimny chip tuning: questions
How much more power does the GAN GT give the Jimny 1.5 DDiS?
The 86 hp version with 200 Nm reaches 112 hp and 260 Nm with the GAN GT in the catalogue; the 65 hp version with 160 Nm is listed as well. These are the stated gains for this engine type, not a dyno reading of your car.
Which module fits the Jimny 1.3 with 80, 82 or 85 hp?
The 1.3 is naturally aspirated and works with the GAN GA+, rated at up to 12% more power. The catalogue lists the 80 hp and 85 hp versions, so go by the year and the figures in your documents.
Does the module affect the automatic gearbox or ALLGRIP PRO?
The module does not reprogram the gearbox. The four-speed automatic is an option on the Jimny III and the Jimny IV, and ALLGRIP PRO is the name of the four-wheel drive system.
Tuning box or ECU remap for a Jimny?
An ECU remap rewrites the factory software, while the GAN tuning module sits between the engine sensors and the ECU and adjusts their signals. Your manufacturer's warranty is preserved: the ECU software is never changed, and the module can be removed at any time.
Is a tuning module the same as a Stage 1 tune?
Not quite. Stage 1 usually means an ECU remap without replacing any parts. The tuning module also works without replacing parts, but it does not change the ECU software: it adjusts the sensor signals, comes off in about a minute, and the OFF button in the app restores the factory settings.
